ISO 1798 Tensile Strength Flexible Cellular Polymeric Materials
The ISO 1798 method determines the tensile and deformation properties of flexible cellular materials when extended at a constant rate of displacement until failure. These properties include tensile strength and elongation at break.
The challenges:
- Specimen gripping
- Repeatable strain measurements
- Reporting test results in compliance with the standard
Our solutions:
- Specimen gripping – Recommended gripping options include pneumatic side action grips and advanced screw action grips. Pneumatic side acting grips provide a constant clamping force to eliminate slippage and produce repeatable results.
- Repeatable strain measurements – Advanced strain solutions include non-contacting extensometers, such as the Advanced Video Extensometer (AVE2) and automatic contacting extensometers, such as the AutoX750. These solutions require little influence from the operator, resulting in improved repeatability. Contacting long travel extensometers also meet the measurement accuracy requirements of the standard.
- Reporting test results in compliance with the standard – Bluehill® Universal testing software offers advanced methods that are available with pre-configured calculations to ensure compliance with the reporting requirements of this standard.
It is important to review ISO 1798 to fully understand the test setup, procedure, and results requirements.
AVE 2 Non-Contacting Video Extensometer
The second generation Advanced Video Extensometer (AVE 2) utilizes patented measurement technology in the fastest, most accurate non-contacting strain measurement device commercially available.
- 产品
- 01/26/2018
- 1.4 MB
Automatic Contacting Extensometer – Model AutoX 750
The AutoX 750 is a high-resolution, long-travel automatic contacting extensometer. It can be mounted onto any electromechanical 3300, 3400, 5500, 5900, or 6800 Series tabletop or floor model system as well as LX, DX, HDX, and KPX static hydraulic testing systems. It is well suited for applications involving plastics, metals, biomedical, composites, elastomers, and more. The AutoX has a maximum travel of 750 mm and accuracy of ± 1 µm.
- 产品
- 08/15/2013
- 1.29 MB
2603-080 Long Travel Extensometer
The Instron® model XL (long travel) extensometer is a precise device for measuring strain in highly extensible materials such as elastomers, semi-rigid plastics and films.
- 产品
- 10/23/2018
- 478.7 KB
2712-04X Series Pneumatic Side-Action Grips
Pneumatic side-action grips offer a versatile gripping solution for a wide range of materials. Rated capacities between 1 and 10 kN.
- 产品
- 03/22/2022
- 1.13 MB
2710 Series Screw Side Action Grips
Screw side-action grips provide a very simple and efficient method for holding test specimens in a wide range of applications. The dual – acting design of 2710-100 series grips means that jaw faces can be adjusted to accommodate different specimen thicknesses. This ensures that the line of tensile force remains concentric with the grip body. They can be equipped with a selection of interchangeable grip jaw faces in various sizes and choice of surfaces including smooth ground, rubber-coated and serrated. Line contact and special coated faces are also available.The unique ‘snap-on’ jaw face attachment makes changing faces extremely quick and simple.
- 产品
- 06/28/2017
- 1.29 MB
3400 Series Universal Testing Systems Brochure
Instron 3400 Series universal testing systems for tensile, compression, bend, and other material property tests.
- 产品
- 06/27/2022
- 2.69 MB
6800 Series Premier Testing Systems Brochure
Instron 6800 Series Universal Testing Systems provide unparalleled accuracy and reliability. Built on a patent-pending Operator Protect system architecture with an all-new Smart-Close Air Kit and Collision Mitigation features, the 6800 Series makes materials testing simpler, smarter, and safer than ever before.
- 产品
- 02/10/2020
- 1.93 MB
Bluehill Universal Brochure
Bluehill Universal is Instron’s advanced materials testing software, designed for intuitive touch interaction and streamlined workflows. It offers pre-loaded test methods, QuickTest for rapid setup, enhanced data exporting, and Instron Connect for direct service communication. Users of Bluehill 2 and Bluehill 3 can easily upgrade to the latest version for improved performance and usability
- 产品
- 02/26/2017
- 3.77 MB
