Composites Test Fixtures: Open Hole Compression
Composite Test Fixtures Open-Hole Compression testing is preformed on multi-directional polymer matrix composite laminates reinforced with high modulus fibers.
제품소개 03/26/2014 174.68 KB
Lap Shear Fixtures
The Lap Shear fixture, for use with Precision Manual Wedge Grips, provides a simple way of ensuring consistent alignment and hence repeatable lap shear test results.
제품소개 03/03/2014 646.44 KB
로드셀 vs. 압력 센서(Transducer)
이 백서에서는 압력 센서(transducer)와 로드셀의 장단점을 비교 분석합니다.
제품소개 02/26/2014 334.19 KB
VisualRHEO | Software for CEAST SR Series Capillary Rheometers
A fundamental part of a capillary rheometer system is the software. As the system investigates the flow behavior of
plastics over a wide range of shear conditions, the software controls the instrument from a PC, acquiring and analyzing
data, calculating results, and exporting data to easily share and perform further analysis. Performing tests that are much
more effective and informative than a trial-and-error approach, the software provides a user-friendly interface for lab
operators when programming and monitoring the tests.
제품소개 02/14/2014 2.46 MB
Split Insert Tensile Grips W-5158 and W-5159
Instron® Split Insert Tensile Grips are designed for safe,
high-volume production testing of shoulder-end or button-head machined specimens. Engineered with an operator focus, the split insert style tensile grips are easy to install, offer quick change inserts for standard specimen sizes, and promote efficient testing of a wide range of metals and alloys.
제품소개 01/30/2014 1.46 MB
2716-111 & 2716-121 Wedge Action Grips & Jaw Faces
The Pneumatic Wedge Action Grips, available in 100 or 200 kN, provide a convenient method of clamping both large round and flat specimen shapes, up to a 50 mm (2 in) diameter, or flat specimens up to 40 mm (1.57 in) thick respectively. V-face grips are used for round specimens by design and have a reduced area at the center that compromises their ability to absorb high-energy breaks without fracture. This grip uses a split V-face configuration that allows the break energy to be dissipated without damaging the faces.
제품소개 01/09/2014 1.26 MB
Composite Test Fixtures_Compression After Impact, ASTM D 7137 / D 7137M
The “Boeing CAI” fixture is used to test the impact resistance of carbon and other fiber-reinforced polymer composite laminates. These materials are prone to great reduction in compressive strength, even when the impact load is insufficient to cause visible damage. The post-impact compression test is used to assess the relative performance of different composite laminates with different fiber matrix combinations. Laminates are subjected to low-velocity impact loading simulating tool drops and flying debris or may be subjected to an out-of-plane static indentation (ASTM D 6264 / D 6264M). Specimens then undergo a compression after impact (CAI) test on an electromechanical or servohydraulic testing machine.
제품소개 12/06/2013 293.65 KB
8800MT Controller Upgrades and Retrofits
The Instron® 8800MT retrofit enables older servohydraulic and dynamic testing systems to be upgraded with the latest control electronics and WaveMatrix™2 software: WaveMatrix2 for fatigue testing or dynamic tests, or Bluehill® 2 for static tests. As many fatigue tester load frames are designed to last and provide many years of reliable testing, the modernization and upgrade of the control system is a cost-effective way to extend the life of your existing installation and test using the latest techniques. 8800MT upgrade packages are available for existing servohydraulic fatigue testing machines including Instron, Schenck, Dartec, MTS, Zwick, Shimadzu, Mayes, and other manufacturers.
제품소개 10/25/2013 719.51 KB
산업용 시리즈 HDX 모델
이중 테스트 공간과 긴 테스트 스트로크가 특징인 HDX 모델은 고용량 인장, 압축, 굽힘/굴곡 및 전단 테스트를 위해 설계되었습니다.
제품소개 10/07/2013 368.13 KB
2640 Series Averaging Transverse Extensometer | 2640-010
The 2640 series averaging transverse extensometer is designed to measure average transverse gauge length and strain with a single output channel.
제품소개 10/07/2013 256.85 KB
