Literatur
Bibliothek mit Druckschriften, Handbüchern, Whitepapers & Fallstudien
CEAST HDT Vicat Testers in Phase 3
The Instron C-0710-500 | 6910 systems are in Life Cycle Phase 3. Products are no longer in production, and service support is on a best-effort basis.
Produkte 05/28/2020 323.98 KB
Automated XY Stage Testing System
The Instron Automated XY Stage Testing System is designed for automated testing of devices or components with multiple test points such as medical devices, syringes, or keypads. The XY stage easily mounts to a 6800 or 5900 Series testing frame. Instron’s Bluehill Universal Software offers complete system control in one package: XY stage movement, method development, test control and results.
Produkte 05/21/2020 430.47 KB
ElectroPuls Prüfsystem mit 16-Stationen
Das Electropuls-Prüfsystem mit 16 Stationen führt Ermüdungsprüfungen mit hoher Lastspielzahl an mehreren Proben gleichzeitig durch, wobei an jeder Station ein für zyklische Versuche konzipierter Kraftaufnehmer vorgesehen ist. Die Vorrichtung ist als Karussell ausgeführt, das mit hoher Steifigkeit und geringer Masse konstruiert wurde, um hochfrequente Prüfungen zu ermöglichen und die Prüfzeit zu verkürzen.
Produkte 05/20/2020 816.06 KB
CEAST TUP Calibrations
Instron professional services are now accredited to carry out on-site NVLAP calibrations for gauged TUPs under 100kN. This calibration can be carried out on your machine thus minimising the amount of time your equipment is down and enabling you to be back up and testing in only a few hours.
Services 05/07/2020 969.86 KB
Expansion Channel Module
The Expansion Channel Module (catalog no. 2210-920) allows 6800 and 5900 Series electromechanical testing systems users to add up to eight channels of signal conditioning and control. The expansion module provides up to a total of 13 transducers for simultaneous monitoring, feedback, and control.
Produkte 04/30/2020 731.36 KB
250 kN Flexure Fixture Data Sheet
The 250 kN flexure fixture (catalog no. 2810-206) allows a variety of flexural and fracture toughness bend tests to be performed, including determination of flexural modulus, flexural strength and flexural yield strength. Easy-to-install, the three-point fixture can be modified with an optional conversion kit to provide a four point bending conversion.
Produkte 04/29/2020 990.9 KB
Debris Shield Single Column Table Model
To protect operators without harming usability, Instron has developed new shields for tabletop and single column systems.
Produkte 04/28/2020 1.59 MB
Traceability Module Data Sheet
Bluehill Universal’s Traceability Module enables users to meet the audit requirements associated with FDA 21 CFR Part 11, ISO 17025, NADCAP, A2LA, and other accrediting bodies. Through seamless integration of electronic signatures and approvals, file revision history, and an automated, secure audit trail, this powerful add-on provides unmatched data traceability.
Produkte 04/09/2020 1.51 MB
Digital I/O Board Guide
The digital I/O board is an optional card which can be added to 5900 and 6800 frames. Digital communication, unlike analog, does not sense continuous signals but inputs or outputs of one of two states: high or low, open or closed. The card used in conjunction with the frame and Bluehill software allows the operator to trigger external or internal events. It allows for 4 input and output channels to be monitored and/or triggered simultaneously.
Produkte 04/01/2020 475.75 KB
Drop Tower impact testing for CAI
To properly understand the performance of Composites, one of the most broadly used methods is the CAI (Compression After Impact) test. Low energy impacts can be considered the most dangerous since the damage they cause can be complex and affect all plies of the structure from matrix and fiber crack to delamination. To ensure a level of high quality and compliance with safety standards, impact testing is a key in gathering knowledge as to how these materials behave and may be damaged when impacted.
Produkte 03/17/2020 532.13 KB
