Literatur
Bibliothek mit Druckschriften, Handbüchern, Whitepapers & Fallstudien
Food Texture Fixtures Probes and Chucks
Flat-end puncture probes produce a shear stress in the specimen. The force required to cause shearing as the probe penetrates the specimen relates to texture properties such as firmness and hardness.
Produkte 11/06/2018 686.36 KB
2603-080 Long Travel Extensometer
The Instron model XL (long travel) extensometer is a precise device for measuring strain in highly extensible materials such as elastomers, semi-rigid plastics, and films.
Produkte 10/23/2018 478.7 KB
Ball Burst Compression Fixture
Burst or puncture fixtures are used to determine the resistance of a material to the penetration of a probe.
Produkte 10/10/2018 200.09 KB
90 Degree and Variable Angle Peel Fixture
Peel fixtures provide a condition of use to measure the bond strength between laminated surface coatings, films, packaging, and their rigid backings, as well as other bonded structures.
Produkte 10/10/2018 902.68 KB
90° Angle Peel Fixture (2820-035)
Both the 90° peel test fixture and the variable angle peel test fixture consist of a bearing-mounted sled that is linked to the testing machine’s crosshead by a cable and pulley system.
Produkte 10/10/2018 590.73 KB
ElectroPuls® Automated XY Stage
The Instron® Automated XY Stage for the ElectroPuls test instrument is designed for automated durability testing. The flexibility of the Automated XY Stage allows it to adapt for testing of many specimens, devices, and components including medical devices, syringes, keypads, and pill crush. Utilizing Instron WaveMatrix2, the software provides ease of control of the system configuration to meet a variety of testing needs.
Produkte 10/04/2018 1.06 MB
Dynacell Fatigue Rated Load Cells
The 2527 Series load cells are designed for use with Dynamic Testing Systems; offering exceptional performance with the ability to measure forces as low as 1/250th of the force capacity to an accuracy of 0.5% of reading. Automatic transducer recognition and electrical calibration, makes them easy to use. The load cells can withstand loads up to 150% of their force capacity without damage and 300% without mechanical failure. All Instron load cells are individually temperature-compensated and tested for accuracy and repeatability on calibration apparatus that is traceable to international standards, with a measurement uncertainty that does not exceed one-third of the permissible error of the load cell.
Produkte 08/17/2018 448.71 KB
CEAST Serie MF Schmelzindexprüfgeräte
Die Fließeigenschaften von geschmolzenen Kunststoffen sind ein wichtiges Merkmal, das eingehendes Knowhow und genaue Kontrolle erfordert. Instron®-Schmelzindexprüfgeräte sind speziell für die unkomplizierte und präzise Bestimmung der Schmelze-Massefließrate (MFR) und der Schmelze-Volumenfließrate (MVR) konzipiert. Das Spektrum von CEAST-Schmelzindexprüfgeräten reicht von Systemen für einfache manuelle Prüfverfahren bis hin zu halbautomatischen Systemen für Mehrgewichtsprüfungen.
Produkte 07/27/2018 1.6 MB
Choice Inputs with Linked Values Bluehill Universal
Choice inputs provide users with a preconfigured list of options that minimize data entry time and reduce the risk of error for commonly used inputs, such as operator name, color or specimen type. Additionally, each choice can be linked with other parameters, such as test rate or dimensions.
Anwendungen 07/17/2018 350.99 KB
Instron HV Series for HDT and Vicat Testing
The effect of temperature on the mechanical properties of plastic materials has a fundamental role in the design of components, especially in the selection of materials. Unlike metals and ceramics, plastics are extremely sensitive to the slightest changes in temperature. The selection of plastics for applications under different temperatures is a complex task. The material must be able to support a stress under operating conditions without losing its strength and without critical distortion. The effect of temperature on geometrical stability and mechanical properties in general can be studied following different procedures and methods like at constant temperature or with a temperature ramp.
Produkte 06/21/2018 1.15 MB
