Literatur
Bibliothek mit Druckschriften, Handbüchern, Whitepapers & Fallstudien
CEAST SmartRHEO Series: Capillary Rheometer Systems
The innovative Instron® line of CEAST SmartRHEO Series of Capillary Rheometer systems are designed for an accurate investigation of the rheological properties of polymeric materials.
Produkte 01/26/2017 186.54 KB
Residual Seal Force (RSF) Testing
Parenteral products contained in vial package systems require
a robust seal at the interface between the glass vial and the
elastomeric closure to prevent contamination and product leakage.
The seal is established in the manufacturing process, but must
withstand a variety of handling, processing and storage conditions.
Anwendungen 01/20/2017 445.94 KB
KPX | Industrial Series | Data Sheet
Industrial Series KPX models are designed for high-capacity tension, compression, bend/flex, and shear testing. Featuring an ultra-large single test space and adjustable crosshead options, these frames deliver exceptional flexibility for a wide range of testing applications and are available in capacities ranging from 600 kN (135,000 lbf) to 3,500 kN (800,000 lbf).
Produkte 01/20/2017 260.23 KB
Understanding gage R&R concepts and its significance for Instron systems
This paper is intended to review the fundamental concept of Gage R&R studies also known as Measurement System Analysis (MSA). Different methods such as ANOVA and Xbar/R can be applied to conduct gage R&R analysis. The paper also presents case studies to understand applications of gage R&R in destructive testing and non-destructive testing and its significance with Instron systems. Furthermore, the concept of type I gage study also known is precision-to-tolerance ratio (P/T) is explained in detail here.
Whitepapers 01/20/2017 399.52 KB
DIC FEA Whitepaper
This paper summarizes investigative testing performed to compare strain results obtained using Instron’s AVE and digital image correlation (DIC) to stress results obtained using Solidworks finite element analysis (FEA)
Whitepapers 01/13/2017 134.02 KB
ISO 9001 Certified Supplier
Earning ISO 9001 certification means that the company has voluntarily
taken it upon itself to conduct their business professionally, responsibly,
reliably, and with accountability.
Services 12/22/2016 649.24 KB
Pneumatic Cord and Yarn Grips 2714-107
Pneumatic tire cord grips provide a convenient method for clamping tire cord and braided wire to reduce the problem associated with testing these materials. A guide pin allows for easy loading onto a graduated radius cam. This cam provides a stress reduced clamping area on the specimen. The clamping mechanism can be activated either automatically or through a foot switch. This allows hands-free grip operation enabling the specimen to be held with both hands, for easy loading. Pneumatic cord and yarn grips provide selectable clamping force to accommodate different materials and excellent follow up action which compensates for decay of the holding force due to specimen creep.
Produkte 12/07/2016 550.24 KB
Pneumatic Fatigue-Rated Wedge Action Grips 2742-103
Designed to suit ElectroPuls™ test instruments, the 2742-103 pneumatic wedge action grips are suitable for tension, compression and reverse-stress testing on a wide range of specimens and materials. The grips are pneumatically operated directly from the machine handset and the open-fronted design provides easy specimen insertion, positioning and clamping.
Produkte 08/01/2016 496.78 KB
